Stinger Wheel Loader Bale Spear – Series 2 XD (BS2-XD)
Stinger Wheel Loader Bale Spear – Series 2 XD (BS2-XD)
Stinger Wheel Loader Bale Spear – Series 2 XD (BS2-XD)

Stinger Wheel Loader Bale Spear – Series 2 XD (BS2-XD)

$1,625.00
Brand: Stinger Attachments

Heavy-Duty Bale Handling for Wheel Loaders & Telehandlers
The Stinger Series 2 XD Bale Spear (BS2-XD) gives wheel loader and telehandler operators the power to move hay bales quickly, safely, and efficiently — without needing a new machine. Built for commercial ag operations, cattle farms, and large-scale hay handling, this two-tine spear delivers the strength and durability required for everyday heavy use.

Featuring two spears spaced 39 inches on center, the BS2-XD offers excellent stability for medium and large round bales as well as big square bales. Choose from 39", 43", or 49" spears, each with replaceable double-nut tines for long service life and easy maintenance.

Rugged Construction for Extreme-Duty Use
The frame is built from 1/2" Grade 50 side plates, a 4"×2"×5/16" top support tube, and a 4"×4"×3/8" bottom tube, giving the BS2-XD the backbone required for wheel loader work. The design includes a built-in safety step and correct geometry for secure, stable bale handling.

Each spear is rated at 3,500 lbs @ 30", giving you more than enough lifting strength for dense crop bales.

Compatible With Wheel Loaders & Telehandlers
The Series 2 XD is engineered for larger machines needing a reliable, high-capacity bale spear. Mount options accommodate common construction-style and agricultural quick-attach carriers.

Perfect For

  • Moving large round bales

  • Handling big square bales

  • High-volume feeding operations

  • Loading/unloading hay trailers

  • Commercial ranch & dairy operations

Built in Minnesota, built from American steel, built to work hard.

Spear Length
Mount Options
$1,625.00

✓ Direct Manufacturer Shipping  |  ✓ Nationwide Delivery

Not Sure It Fits? Check Compatibility

Need help? Call or text: 262-402-0444

Request a Quote
More Details:

Two-tine spear layout (39" spacing)
Available spear lengths: 39", 43", 49"
Usable lengths: 33", 37", 43.5"
Rated 3,500 lbs @ 30"
Replaceable tines (double-nut design)
4"×2"×5/16" top support tube
4"×4"×3/8" bottom tube
1/2" Grade 50 steel side plates
Built-in safety step
Designed for wheel loaders & telehandlers
Ideal for square and large round bales
American-made construction
Extreme-duty Series 2 XD build

Freight shipping rates shown below. Built for commercial, agricultural, and land-clearing operations.

Commercial Freight Shipping (Dock Required)
Business location with loading dock required

Zone 1 (WI, MN, IA): $175
Zone 2 (SD, ND, NE, OK, KS, MO, IL, MI, IN, OH, TN, KY, AR): $250
Zone 3 (NV, AZ, NM, CO, UT, TX, LA, MS, AL, GA, SC, NC, VA, WV, DC, MD, DE, NJ, PA, NY): $325
Zone 4 (WA, ID, MT, CA, FL, CT, RI, MA, VT, NH, ME): $375

Non-Dock Delivery (Farm, Ranch, Home, Residential)
No loading dock available

Zone 1: $225
Zone 2: $300
Zone 3: $375
Zone 4: $425

Important Freight Notes
Please call us for combined shipping on multiple items
Delivery address must be tractor-trailer accessible
Unloading equipment required at delivery
Commercial addresses must have regular business hours
No residential dwellings on commercial property
