Stinger Manure Spear Grapple Bucket (MSG)
Stinger Manure Spear Grapple Bucket (MSG)
Stinger Manure Spear Grapple Bucket (MSG)
Stinger Manure Spear Grapple Bucket (MSG)

Stinger Manure Spear Grapple Bucket (MSG)

$3,695.00
Brand: Stinger Attachments

A High-Capacity Manure Spear Grapple Built for Real Farm Work
The Stinger Manure Spear Grapple Bucket (MSG) is designed for livestock producers and ag operators who need a strong, high-capacity attachment for handling loose, matted, or heavy material. Whether you're spreading bedding, removing pen pack, moving silage, or clearing debris, the MSG delivers maximum efficiency with powerful clamping force and deep spear penetration.

Strong Spears, Strong Frame, Strong Grip
Constructed with structural-grade steel and heavy-duty components, this spear grapple uses 37" Conus 2 replaceable bale spears arranged on 8-inch centers (approx. 6-inch openings) to slide under bedding, hay, pen pack, and compacted livestock material with ease. Every spear is bolt-in and replaceable, keeping the bucket performing like new for years.

The twin independent grapples clamp down firmly on uneven or loose loads, powered by greaseable pivots and equipped with ½" flat-face couplers for easy hookup. The 48” grapple opening allows you to grab more per scoop and keep loads secure across bumpy ground or uneven terrain.

Versatile for Much More Than Manure
While built for agriculture, this grapple also excels at moving brush, logs, debris, and organic material. It's a versatile tool for farm, acreage, and construction cleanup.

Sizes & Weights

  • 60" — 830 lbs — 8 spears

  • 68" — 870 lbs — 9 spears

  • 76" — 910 lbs — 10 spears

  • 84" — 950 lbs — 11 spears

Specifications

  • Spear Length: 37" Conus 2 spears (replaceable)

  • Grapple Opening: 48"

  • Spear Spacing: 8" on center (approx. 6" opening)

  • Construction: Structural steel frame

  • Mount: Universal skid steer hookup (other options available)

  • Grapples: Independent, greasable

  • Couplers: ½" flat-face couplers

  • Back Options: Standard open-back; closed-back available

Made American tough — built for chores, built for cleanup, built to last.

Size
Back Option
XD Grapples
$3,695.00
More Details:

Heavy-duty structural steel construction
37" Conus 2 replaceable bale spears
Spears spaced 8" on center (approx. 6" openings)
Independent grapples with strong clamping force
48" grapple opening for large loads
Greaseable grapple pivots for long-term durability
Bolt-in replaceable spears for easy maintenance
Universal skid steer mount (custom mounts available)
Available in 60", 68", 76", and 84" widths
Ideal for manure, silage, bedding, brush, and debris
Supports both agricultural and general land management tasks
Built in the USA with high-grade steel

Freight shipping rates shown below. Built for commercial, agricultural, and land-clearing operations.

Commercial Freight Shipping (Dock Required)
Business location with loading dock required

Zone 1 (WI, MN, IA): $175
Zone 2 (SD, ND, NE, OK, KS, MO, IL, MI, IN, OH, TN, KY, AR): $250
Zone 3 (NV, AZ, NM, CO, UT, TX, LA, MS, AL, GA, SC, NC, VA, WV, DC, MD, DE, NJ, PA, NY): $325
Zone 4 (WA, ID, MT, CA, FL, CT, RI, MA, VT, NH, ME): $375

Non-Dock Delivery (Farm, Ranch, Home, Residential)
No loading dock available

Zone 1: $225
Zone 2: $300
Zone 3: $375
Zone 4: $425

Important Freight Notes
Please call us for combined shipping on multiple items
Delivery address must be tractor-trailer accessible
Unloading equipment required at delivery
Commercial addresses must have regular business hours
No residential dwellings on commercial property

Stinger Attachments warrants each new product manufactured by us to be free from defects in material and workmanship for a period of Twenty-Four (24) months from date of delivery to the original purchaser. Certain Items may have an extended warranty, such as Cascade forks and Eaton drive motors. Please check each product page for more information.

All returns must be in new condition with all freight costs the responsibility of the buyer. No returns accepted after 10 days of buyer receiving the product.
