Stinger Skid Steer Material Bucket – Series 4
Stinger Skid Steer Material Bucket – Series 4
Stinger Skid Steer Material Bucket – Series 4

Stinger Skid Steer Material Bucket – Series 4

$2,195.00
Brand: Stinger Attachments

A High-Capacity Material Bucket Built for Big Machines and Bigger Jobs
The Stinger Series 4 Material Bucket is built for operators who need more capacity, more strength, and more durability from their bucket. As a step up from our Series 3, the Series 4 features a ¼" Grade 50 shell and is engineered to stand up to the largest skid steers on the market — day after day, job after job.

More Volume. More Strength. More Control.
Available in widths from 60" to 84", this bucket delivers increased material capacity with a deep 40" design that improves visibility of the cutting edge. The reinforced top channel brace and bottom-radius support add stiffness, durability, and excellent clean-out performance. With a 68° back angle, this bucket is optimized for smooth rollback and efficient dumping across a wide range of machines.

Cutting Edge Options for Any Job
Choose the cutting edge style that fits your work:

  • Option 1 — Weld-On Edge: 3/4" x 8" welded cutting edge

  • Option 2 — Bolt-On Edge: 1/2" x 6" welded base edge with a 3/4" x 6" bolt-on replaceable edge

Both options provide long service life and dependable scraping power.

Built to Fit Your Skid Steer or Custom Mount
Every Series 4 bucket includes a universal skid steer mount plate, but we can also custom-fit other mounting styles or ship the bucket plain for your own fabrication. Additional reinforcements — including ½" thick side braces, rolled inserts, and 4" wear bars — make this bucket ready for high-demand material handling.

Specifications

  • Shell: 1/4" Grade 50 steel

  • Depth: 40"

  • Cutting Edges: Weld-on or bolt-on configurations

  • Sides: 1/4" with 1/2" side braces

  • Wear Bars: 4" wide x 1/2" thick

  • Top Reinforcement: Structural tube for added strength & visibility

  • Back Angle: 68°

  • Mounting: Universal skid steer plate (custom options available)

  • Included: Step plate for easy machine access

Made in America and built to handle the biggest machines with confidence.

Options
$2,195.00
More Details:
No Video

1/4" Grade 50 steel shell for heavy-duty durability
Deep 40" bucket design for increased capacity and visibility
Weld-on or bolt-on cutting edge options
1/4" sides with 1/2" thick side braces for added structural support
4" x 1/2" wear bars extend bucket life and resist abrasion
Reinforced top tube for strength and improved operator visibility
1/4" rolled insert for better clean-out and added strength
68° back angle for efficient rollback and dumping
Universal skid steer mount included (custom mounts available)
Integrated step for easier cab entry

Freight shipping rates shown below. Built for commercial, agricultural, and land-clearing operations.

Commercial Freight Shipping (Dock Required)
Business location with loading dock required

Zone 1 (WI, MN, IA): $175
Zone 2 (SD, ND, NE, OK, KS, MO, IL, MI, IN, OH, TN, KY, AR): $250
Zone 3 (NV, AZ, NM, CO, UT, TX, LA, MS, AL, GA, SC, NC, VA, WV, DC, MD, DE, NJ, PA, NY): $325
Zone 4 (WA, ID, MT, CA, FL, CT, RI, MA, VT, NH, ME): $375

Non-Dock Delivery (Farm, Ranch, Home, Residential)
No loading dock available

Zone 1: $225
Zone 2: $300
Zone 3: $375
Zone 4: $425

Important Freight Notes
Please call us for combined shipping on multiple items
Delivery address must be tractor-trailer accessible
Unloading equipment required at delivery
Commercial addresses must have regular business hours
No residential dwellings on commercial property

Stinger Attachments warrants each new product manufactured by us to be free from defects in material and workmanship for a period of Twenty-Four (24) months from date of delivery to the original purchaser. Certain Items may have an extended warranty, such as Cascade forks and Eaton drive motors. Please check each product page for more information.

All returns must be in new condition with all freight costs the responsibility of the buyer. No returns accepted after 10 days of buyer receiving the product.
